Fire-Lite DACT-UD2 Digital Alarm Communicator/Transmitter User Manual
Page 17
DACT-UD2 Installation
DACT-UD2 Communicator PN 53037:B 4/01/08
17
Figure 2.6 DACT-UD2 Installation
Customer Premises Equipment and Wiring
Telephone
Line
MS-9600LS with DACT-UD2
Network
Service
Provider’s
Facilities
Network
Demarcation
Point
RJ31X
Jack
Unused
RJ-11 Jack
Unused
RJ-11 Jack
Telephone
Telephone
Telephone
Answering
System
Fax Machine
Computer
It is critical that the DACT be located as the first device on the incoming telephone circuit to properly function.
