Installing the Charger
Connecting the Charger to a Load
18
CHG-120F Instruction 03/21/01 PN 50888:B0
Connecting the Charger to an MS-9600 - A charger can be connected to an MS-9600
as illustrated in Figure 11.
Figure 11 Typical Wiring of a Charger to an MS-9600
To connect a charger as shown in Figure 11, follow these steps:
Step Action
1 Cut jumper JP3, on the MS-9600 main circuit board to disable the FACP battery
charger.
2 Connect the battery cables between TB2 (+ and –) on the MS-9600 and the CHG-
120F charger output circuit (TB2: Out 1+ and Out 1–) as shown in Figure 11. Be
certain to observe polarity.
3 If needed, connect the battery+ and battery– terminals of an optional external device
to the charger output circuit (TB2: Out 2+ and Out 2–) as shown in Figure 11.
4 Connect the batteries to the charger (for battery connections see Figure 5 or Figure 6).
+B AT TE RY-
LCD D ISPLAY K EY PA D I /F
S EC URITY O PT BD
O PT DA CT
HO T CB1
J3
J12
J2
TB1 TB2
TB3
JP3
JP2
SW1
JP5 JP6
J17 J16 J6 J8
J7
J10 J11
CUT TO
DISA B LE
LOC AL
CHA RG ER
DISA B LE
G ND
FLT
CUT TO
MO NITO R 4X TM
O PT S LC
4XT M O PT B D
TB4 TB5 TB6 TB7 TB8
NEUT E ART H
Ba
tt
e
ry
–
2 5 A H
(1 2 V ) 2 5 A H
(1 2 V )
– + – +
T B 2
TB1
–
+
–
+
–
+
Ba
tt
e
ry
+
B atter y In ter co n n e ct C a b le
C ha rger
To A uxilia ry
E q uipm en t
A C P o w e r In
Neu
t
Gr
d
Ho
t
Ou
t 2
-
O u t 1 +
O u t 1 -
Ou
t 2
+
MS-9600
+ –
Cut JP3
