Edwards Signaling 103I Series - Manual

P/N 3100415 ISSUE 1 © 2001
Installation Instructions for Chameleon TM 103I Series
LED Multi-Status Indicator in NEMA 4X Enclosures
Description
The 103 Series Chameleon Multi-Status LED Indicator is a UL
and cUL listed, CE marked multi-color LED signaling appliance
in a NEMA 4X and IP65 rated enclosure. The modules can be
panel mounted or conduit mounted.
The lights are available in 24V DC and 120V 50/60 Hz. They are
available in either red, blue and amber or red, green and amber.
The lights are designed such that any one or all three lights can be
activated by either a PLC or contact closure. The first light acti-
vated can be either steady or flashing.
Specifications
WARNING
To prevent electrical shock, ensure that power is turned
off before installing the signal.
5. Turn on power and verify that the signal operates properly.
Panel Mounting (Figure 3)
Note: The integrity of the outdoor, NEMA 4X, and IP65 rating on
the panel assembly at the interface with the 103 Series Chame-
leon Visual Status Indicator relies on the construction and con-
figuration details of the mounting surface. Installer should evalu-
ate.
1. If the unit is not being flashed by a PLC and it is desired for
the first light to illuminate flashing, the jumper must be
installed as follows.
a. Remove (4) screws securing the lens to the base from
bottom of base (Figure 3) and remove lens.
b. Install the jumper on pins 1 and 2 (Figure 1) for PLC
flashing. The unit is supplied with the jumper installed
on pins 2 and 3 for a steady illumination.
c. Replace lens on base and secure with (4) screws removed
in step 1a.
2. Place the mounting gasket (supplied) over the hole in the
panel and route the signal wires through the gasket and the
hole in the panel.
3. Insert the base through the hole in the panel and screw the
locking nut (supplied), with the raised locking edge facing
the mounting surface, onto the base to secure the beacon.
4. Wire the beacon as follows:
a. For AC models: There are four 18" wire leads: white
(neutral), red (for activation of red LEDs), white with green
stripe or blue (for activation of green or blue LEDs--
depending on model) and amber (for activation of amber
LEDs).
Using wire nuts, connect white lead to AC neutral and
connect each of the other three leads to AC hot.
Catalog
Number Voltage Current Colors
103I-RGA-N5 120V 50/60 Hz 0.045 A red, green, amber
103I-RBA-N5 120V 50/60 Hz 0.045 A red, blue, amber
103I-RGA-G1 24V DC 0.055 A red, green, amber
103I-RBA-G1 24V DC 0.055 A red, blue, amber
Installation
The unit is factory shipped such that a contact closure will cause
the first light activated to illuminate steady (unless activated by a
PLC). If a second light is activated, the unit will cycle between
the two selected colors. Likewise, a third activation will cause the
unit to cycle between the three colors: red, amber, green or red,
amber, blue.
If it is desired for the first light to illuminate flashing, install the
jumper on pins 1 and 2 as shown in Figure 1. A contact closure
will then cause the first light activated to illuminate flashing. If a
second light is activated, the unit will cycle between the two se-
lected colors. Likewise, a third activation will cause the unit to
cycle between three colors: red, amber, green or red, amber, blue.
Conduit Mounting (Figure 2)
1. If the unit is not being flashed by a PLC and it is desired for
the first light to illuminate flashing, the jumper must be
installed as follows.
a. Remove (4) screws securing the lens to the base from
bottom of base (Figure 3) and remove lens.
b. Install the jumper on pins 1 and 2 (Figure 1) for PLC
flashing. The unit is supplied with the jumper installed
on pins 2 and 3 for a steady illumination.
c. Replace lens on base and secure with (4) screws removed
in step 1a.
2. Thread the 18" (45.7 cm) signal wire leads through either 1/2"
(13mm) or 3/4" (19 mm) conduit into an approved conduit
outlet box. (Product is supplied with a double threaded - 1/2"
(13mm) internal and 3/4" (19mm) external - conduit hub.)
3. Wire the beacon as follows:
a. For AC models: There are four 18" wire leads: white
(neutral), red (for activation of red LEDs), white with green
stripe (for activation of green or blue LEDs--depending
on model) and amber (for activation of amber LEDs).
Using wire nuts, connect white lead to AC neutral and
connect each of the other three leads to AC hot.
b. For DC models: There are four 18" wire leads: black
(common), red (for activation of red LEDs), white with
green stripe (for activation of green or blue LEDs--
depending on model) and amber (for activation of amber
LEDs).
Using wire nuts, connect black lead to DC common and
connect each of the other three leads to DC hot.
4. Thread the conduit onto the base of the signal.
WARNING
To avoid risk of injury, install lens before energizing the
unit.
NEW
Positive Switching
