PART NUMBER 1 CONTACT 2 SENSE RANGE 3 SENSE RANGE 3 BREAK LEAD LENGTH
391 or 393 CONFIGURAT MINIMUM MAXIMUM RANGE NOMINAL
391-BT-06(J)(K) DPST: 1 N.O., 1 N.C. 0.3"(0.8cm) 0.6"(1.5cm) 1.2"(3.0cm) 6' (1.8m)
391-BT-12(J)(K) DPST: 1 N.O., 1 N.C. 0.3"(0.8cm) 0.6"(1.5cm) 1.2"(3.0cm) 12' (3.6m)
391-BLT-06(J) DPST: 1 N.O., 1 N.C. w/LED 0.3"(0.8cm) 0.6"(1.5cm) 1.2"(3.0cm) 6' (1.8m)
391-BLT-12(J)(K) DPST: 1 N.O., 1 N.C. w/ LED 0.3"(0.8cm) 0.6"(1.5cm) 1.2"(3.0cm) 12' (3.6m)
391-B3LT-12(J) TPST: 2 N.O., 1 N.C. w/LED 0.3"(0.8cm) 0.6"(1.5cm) 1.2"(3.0cm) 12' (3.6m)
391-B3LT-20(J) TPST: 2 N.O., 1 N.C. w/LED 0.3"(0.8cm) 0.6"(1.5cm) 1.2"(3.0cm) 20' (6.1m)
Ordering Information
CIRCUIT CIRCUIT CONTACT LOAD SWITCHING SWITCHING
NUMBER TYPE CONFIGURATIO RATING VOLTAGE CURRENT
1 Switch: S1 N.O. 40W/VA 48VAC/VDC 1.0ADC, 0.7AAC
2 Tamper: S2, S3, S4 N.C. 10W/VA 48VAC/VDC 0.3A
2 w/optional LED: D1 N.C. 0.1–1.4W 48VDC(3V drop) 30mA
3 Monitor: S5 N.O. 10W/VA 48VAC/VDC 0.3ADC, 0.3AAC
Electrical Specifications
Accessories
PART NUMBER TAMPER PROOF SCREWS & SCREWDRIVER
1953 #6 x 3/4"L Tampruf Roundhead Screw
1954 #8 x 1-1/2"L Tampruf Roundhead Screw
1955 Tampruf ® Screwdriver
1956 Tampruf ® 1/4" Drive Bit for #6 and #8 screws
Warning— Each electrical rating is an individual maximum and cannot be exceeded!
1 The part numbers 391 and 393 are the same in all respects except the cable exits 391 left and 393 right. Not all models available in 393.
2 Configuration with actuator away from the switch
3 Proximity of ferrous materials usually reduces sense range — typically by 50%. The shape and type of material cause a wide diversity of effects.
Testing is required to determine actual sense range for specific applications.
