P/N 3101650 ISSUE 3
Figure 3. Lamp Replacement
Table 1. Replacement Parts
Catalog Number
(gray base)
Catalog Number
(black base)
Replacement
Lens Replacement Lamp
Flashing Halogen
125HALF*24D 125HALF*24DB
125L(*)
50LMP-9WH-D or industry trade
no. 1692** (incandescent)
125HALF*24A 125HALF*24AB
125HALF*120A 125HALF*120AB 50LMP-12WH-D or industry trade
no. 15T7DC** (incandescent)
Steady-On Halogen
125HALS*24D 125HALS*24DB
125L(*)
50LMP-9WH-D or industry trade
no. 1692** (incandescent)
125HALS*24A 125HALS*24AB
125HALS*120A 125HALS*120AB 50LMP-12WH-D or industry trade
no. 15T7DC** (incandescent)
*Letter in this position indicates lens color:
A - Amber, B - Blue, C - Clear, G - Green, R - Red
**The listed non-halogen lamp may be used in place of the halogen lamp.
Lens
Lamp
(Halogen Lamp Shown)
Lamp Socket
O-Ring (in groove)
(supplied)
Base
(4) Screws securiing
lens to base
