© Trynex International 2012 (REV A) F50766 16
Harness Diagram
Operating the PWX
Model # PWX-200 / PWX-250
Enabling the Pre-Wet Function:
Maintenance
Fill the Tanks with the pre-wet solution of your preference.
Turn Control Pendant on.
Push the “Pre-Wet Enable” button; a light will turn on.
Begin spreading by pushing the “Start” button. The Pump will turn on with the with the Auger and Spinner. The flow rate will adjust automatically.
The pre-wet solution and the spreading material will mix in the Auger Discharge Tube.
To stop Pre-Wetting the spreading material push the “Pre-Wet Enable” button; the light will turn off. Otherwise the PWX is integrated with the
spreader controls and the pump will stop operating when you push “Start-Stop.”
To adjust the flow rate of the PWX system, adjust the valve in the hose.
Paint or Oil scratches in the paint/metal.
Do not clean tanks with petroleum products. This will damage the tanks.
Periodically apply Dielectric Grease to electrical connections to prevent corrosion.
Empty Tanks and Spreader’s Hopper after each use to prevent freezing.
To drain tanks; remove the cap from the driver’s side tank.
Store system indoors or use run RV Antifreeze through pump and store with RV Antifreeze in Pump.
F50681 PWX Relay Wire
F50679 PWX Pump Harness
8.00
