SANDPIPER M1F Non-Metallic - Manual (Page 6)

m1fnmdl3sm-rev0713 Model M1F Non-Metallic Page 4
Dimensions: M1F Non-Metallic Inline Ported Option - Polypropylene Wet End Models ONLY
Dimensions in inches
Dimensions in millimeters (metric dimensions in brackets)
2.50 64
17.12 435
19.94 506
18.18 462
SUCTION PORT
1" FNPT
SUCTION PORT (OPTIONAL)
1" FNPT
DISCHARGE PORT (OPTIONAL)
1" FNPT
A
9.81 249
2X 2.15 55
4.96 126
.50 13
DISCHARGE PORT
1" FNPT
AIR INLET
1/2 FNPT
4.06 103
10.09 256
4X .53 13
MTG. SLOT
STANDARD INTEGRAL MUFFLER
GENERAL NOTES
OPTIONAL SUCTION & DISCHARGE SIDE PORTS WILL BE PLUGGED AT 1.
FACTORY, NOT SHOWN
STANDARD INTEGRAL MUFFLER (SHOWN) COVERS 1" FNPT EXHAUST PORT 2.
FOR OPTIONAL MUFFLER STYLES OR PIPING EXHAUST AIR IN SUBMERGED
APPLICATIONS
S1F NON-METALLIC
IN-LINE PORTED OPTION
DIMENSIONAL TOLERANCE = .125 [3mm]
B.1 REMOVED ALL TABULATED DIMENSIONS EXCEPT "A" MF 4/23/2010
A.1 RELEASED FOR GENERAL USE MF 2/4/2010
REV REVISION CHG DATE APP DATE ECN
Standard Integral
Muffler Option
Mesh & Sound
Dampening Muffler
Option
A 11.81 [300] 13.50 [343]
THIS IS A PROPRIETARY DOCUMENT. DO NOT REPRODUCE OR DISCLOSE
WITHOUT THE EXPRESS WRITTEN PERMISSION OF IDEX AODD
MADE FROM
ASS'Y REFERENCE PUMP REFERENCE
MATERIAL
PART NUMBER
DESCRIPTION
DRAWING NUMBER
IDEX AODD
REV
B.1
UNLESS OTHERWISE
SPECIFIED
TOLERANCES
.XX .XXX .010 .005
ANGULAR 1/2
SURFACE FINSH
63
DO NOT SCALE DRAWING
DIMENSIONS ARE INCHES
SHEET
C
6 7 8
A
8 7 6 5 4 3 2 1
D
B
D
C
B
A
450.468.000
OUTLINE, PUMP, S1F, ONE PIECE MANIFOLD
1 1 of
S1F NON-METALLIC
