m1fnmdl3sm-rev0713

Model M1F Non-Metallic Page 2

Explanation of Pump Nomenclature

M1F Non-Metallic · Design Level 3 · Ball Valve

Check

Diaphragm/

Check

Non-Wetted

Shipping

Model

Pump Pump Valve Design Wetted

Check Valve Valve

Material

Porting Pump Pump

Kit

Weight

Brand Size

Type

Level Material

Materials

Seat

Options Options Style Options Options lbs. (kg)

M1FB3P1PPUS000.

M

1F

B

3

P

1

P

P

U

S

0

00.

42 (19)

M1FB3P2PPUS000.

M

1F

B

3

P

2

P

P

U

S

0

00.

42 (19)

M1FB3PBPPUS000. M

1F

B

3

P

B

P

P

U

S

0

00.

42 (19)

M1FB3PGPPUS000. M

1F

B

3

P

G

P

P

U

S

0

00.

42 (19)

M1FB3PNPPUS000. M

1F

B

3

P

N

P

P

U

S

0

00.

42 (19)

M1FB3K1KPUS000.

M

1F

B

3

K

1

K

P

U

S

0

00.

54 (24)

M1FB3K2KPUS000.

M

1F

B

3

K

2

K

P

U

S

0

00.

54 (24)

Pump Brand

M= MARATHON

®

Pump Size

1F= 1" Full Flow
Check Valve Type

B= Ball
Design Level

3= Design Level 3
Wetted Material

K= PVDF

P= Polypropylene

C= Conductive Polypropylene

V= Conductive PVDF

Diaphragm Check Valve Materials

1= Santoprene/Santoprene

2= PTFE Santoprene Backup/PTFE

3= PTFE Pumping, PTFE-Santoprene

Backup Driver/PTFE

4= Santoprene Pumping/Santoprene

B= Nitrile/Nitrile

G= PTFE-Neoprene Backup/PTFE

N= Neoprene/Neoprene

V= FKM/FKM

Y= PTFE Pumping/One-Piece Bonded

Driver/PTFE

Z= One-Piece Bonded/PTFE
Check Valve Seat

K= PVDF

P= Polypropylene
Non-Wetted Material Options

P= Polypropylene

1= 40% Glass Filled Polypropylene

with PTFE hardware

C= Conductive Polypropylene

Porting Options

N= NPT Thread

U= Universal (Fits ANSI and DIN)

7= Dual Porting (ANSI)

8= Top Dual Porting (ANSI)

9= Bottom Dual Porting (ANSI)
Pump Style

D= With Electronic Leak

Detection (110 V)

E= With Electronic Leak

Detection (220V)

I= Inline Porting NPT Threads

M= With Mechanical

Leak Detection

S= Standard

V= With Visual Leak Detection
Pump Options

0= None

1= Sound Dampening Muffler

2= Mesh Muffler

3= High temperature Air Valve

w/Integral Muffler

Kit Options Continued

E3.= Solenoid Kit with 12VDC

Explosion-Proof Coil

E4.= Solenoid Kit with 110VAC Coil

E5.= Solenoid Kit with 110VAC

Explosion-Proof Coil

E6.= Solenoid Kit with 220VAC Coil

E7.= Solenoid Kit with 220VAC

Explosion-Proof Coil

E8.= Solenoid Kit with 110VAC, 50 Hz

Explosion-Proof Coil

E9.= Solenoid Kit with 230VAC, 50 Hz

Explosion-Proof Coil

SP.= Stroke Indicator Pins
A1.= Solenoid Kit with 12 VDC

ATEX Compliant Coil

A2.= Solenoid Kit with 24 VDC

ATEX Compliant Coil

A3.= Solenoid Kit with 110/120 VAC

50/60 Hz ATEX Compliant Coil

A4.= Solenoid Kit with 220/240 VAC

50/60 Hz ATEX Compliant Coil

Kit Options

00.= None

P0.= 10-30VDC Pulse Output Kit

P1.= Intrinsically-Safe 5-30VDC,

110/120VAC 220/240 VAC

Pulse Output Kit

P2.= 110/120 or 220/240VAC

Pulse Output Kit

E0.= Solenoid Kit with 24VDC Coil

E1.= Solenoid Kit with 24VDC

Explosion-Proof Coil

E2.= Solenoid Kit with 24VAC/12VDC Coil

Note: Pumps are only ATEX com-

pliant when ordered with wetted

material option C or V, non-

wetted material option C, pump

option 0, 6 or 7, and kit option 0.

II 2GD T5

(1)

Note: Pumps ordered with

the options listed in (1) to the

left are ATEX compliant when

ordered with kit option P1.

II 2G Ex ia c IIC T5
II 2D c iaD 20 IP67 T100˚C

(2)

Note: Pumps ordered with the

options listed in (1) to the left are

ATEX compliant when ordered with

kit option A1, A2, A3, or A4. Com-

pressed Air Temperature Range: Maximum

Ambient Temperature to plus 50°C.

II 2G EEx m c T5
II 2D c IP65 T100°C

(3*)

IEC EEX m T4

Note: Pump models equipped with these

explosion-proof solenoid kit options E1,

E3, E5, E7, E8 or E9, are certified and

approved by the above agencies. They are

NOT ATEX compliant.

(4)

Pump Options Continued

4= High temperature Air Valve

w/Sound Dampening Muffler

5= High temperature Air

Valve w/Mesh Muffler

6= Metal Muffler

7= Metal Muffler with Grounding

Cable

Note: Models listed in the table are for reference only. See nomenclature below for other models.

*Note: See page 24 for

Special

Conditions For Safe Use.

II 1G c T5

II 3/1 G c T5

II 1D c T100°C

I M1 c

I M2 c

II 2G Ex ia c IIC T5

II 3/2 G Ex ia c IIC T5

II 2D Ex c ia 20 IP67 T100°C

II 2G EEx m c II T5

II 3/2 2G EEx m c II T5

II 2D c IP65 T100°C
