SANDPIPER M1F Non-Metallic - Manual (Page 17)

m1fnmdl3sm-rev0713 Model M1F Non-Metallic Page 15
Composite Repair Parts List
ITEM PART NUMBER DESCRIPTION QTY
1 031-140-000 Air Valve Assembly 1
031-140-001 Air Valve Assembly (No Muffler) 1
031-140-002 Air Valve Assembly w/PTFE Coated Hardware 1
031-141-000 Air Valve Assembly (No Muffler) 1
031-141-001 Air Valve Assembly (No Muffler) 1
031-141-002 Air Valve Assembly (No Muffler / PTFE Hardware) 1
031-146-000 Air Valve Assembly (With Stroke Indicator Option) 1
031-147-000 Air Valve Assembly (No Muffler w/Stroke Indicator) 1
2 050-042-354 Ball, Check 4
050-042-360 Ball, Check 4
050-042-363 Ball, Check 4
050-042-365 Ball, Check 4
050-042-600 Ball, Check 4
3 095-110-558 Pilot Valve Assembly 1
4 114-024-551 Intermediate Assembly 1
114-024-559 Intermediate Assembly 1
5 132-035-360 Bumper, Diaphragm 2
6 135-034-506 Bushing, Plunger 2
7 165-125-551 Cap, Air Inlet 1
165-125-559 Cap, Air Inlet 1
8 170-020-115 Capscrew, Hex HD 3/8 - 16 x 2.00 16
170-020-308 Capscrew, Hex HD 3/8 - 16 x 2.00 16
9 170-030-115 Capscrew, Hex HD 1/2 - 13 x 2.00 (not used with inline option) 16
170-030-308 Capscrew, Hex HD 1/2 - 13 x 2.00 (not used with inline option) 16
10 170-052-115 Capscrew, Hex HD 3/8 - 16 x 2.25 16
170-052-308 Capscrew, Hex HD 3/8 - 16 x 2.25 16
11 170-069-115 Capscrew, Hex HD 5/16 - 18 x 1.75 4
170-069-308 Capscrew, Hex HD 5/16 - 18 x 1.75 4
12 171-053-115 Capscrew, Soc HD 3/8 - 16 x 2.50 4
13 171-015-115 Capscrew, Soc HD 3/8 - 16 x .88 8
171-015-308 Capscrew, Soc HD 3/8 - 16 x .88 8
14 196-157-520 Chamber, Outer 2
196-157-521 Chamber, Outer 2
196-157-552 Chamber, Outer 2
196-157-557 Chamber, Outer 2
15 196-177-551 Chamber, Inner 2
196-177-559 Chamber, Inner 2
16 286-107-354 Diaphragm 2
286-107-360 Diaphragm 2
286-115-000 Diaphragm, One-Piece Bonded 2
286-107-363 Diaphragm 2
286-107-365 Diaphragm 2
17 286-108-600 Diaphragm, Overlay 2
18 312-104-520 Elbow 2
312-104-521 Elbow 2
312-104-557 Elbow 2
312-104-552 Elbow (not used with inline option) 2
19 312-113-520 Elbow, Suction 2
312-113-521 Elbow, Suction 2
312-113-552 Elbow, Suction (not used with inline option) 2
312-113-557 Elbow, Suction 1
20 360-093-360 Gasket, Air Valve 1
21 360-103-360 Gasket, Pilot Valve 1
22 360-104-360 Gasket, Air Inlet 1
360-104-379 Gasket, Air Inlet 1
23 360-107-360 Gasket, Inner Chamber 2
24 518-179-520 Manifold 2
518-179-521 Manifold 2
518-179-552 Manifold 2
518-179-557 Manifold 2
25 544-002-115 Nut, Hex 3/8 - 16 32
544-002-308 Nut, Hex 3/8 - 16 32
26 545-008-115 Nut, Hex 1/2 - 13 (not used with inline option) 16
545-008-308 Nut, Hex 1/2 - 13 (not used with inline option) 16
27 560-001-360 O-ring 2
28 612-200-157 Inner Diaphragm Plate 2
612-200-082 Inner Diaphragm Plate 2
612-220-150 Inner Diaphragm Plate (One-Piece Bonded Option) 2
29 612-204-520 Outer Diaphragm Plate 2
612-204-552 Outer Diaphragm Plate 2
30 620-020-115 Plunger, Actuator 2
31 670-048-520 Retainer, Ball 4
670-048-552 Retainer, Ball 4
32 675-042-115 Ring, Retainer 2
33 685-058-120 Rod, Diaphragm 1
34 720-004-360 Seal, Diaphragm Rod 2
35 720-044-600 Seal, Manifold Spacer (not used with inline option) 4
36 720-047-600 Seal, Check Valve 8
37 722-079-520 Seat, Check Valve 4
722-079-552 Seat, Check Valve 4
38 901-038-115 Washer, Flat 5/16" 4
901-038-308 Washer, Flat 5/16" 4
39 901-046-115 Washer, Flat 1/2" (not used with inline option) 32
901-046-308 Washer, Flat 1/2" (not used with inline option) 32
40 901-048-115 Washer, Flat 3/8" 4
901-048-308 Washer, Flat 3/8" 4
41 901-049-115 Washer, Flat 3/8" 32
901-049-308 Washer, Flat 3/8" 32
62 518-203-552 Manifold, Suction (Inline Porting Option ONLY) 1
63 518-204-552 Manifold, Discharge (Inline Porting Option ONLY) 1
64 P16NP Plug, 1" NPT Pipe ((Inline Porting Option ONLY) 2
ITEM PART NUMBER DESCRIPTION QTY
Note: ATEX Compliant
