Connecting the control-wire cables >
34020846EN/AD
- Page 46
1. Installation
1.10 Connecting the control-wire cables
Connecting a modular UPS or frequency converter alone.
The maximum total length of CAN inter-cabinet cables must not exceed 180m.
This operation must be carried out by qualified personnel.
The door must be open.
Key
(1) Connectors
1. Fit a blue plug on connector XM06
in the UPS.
2. Fit a red plug on connector XM7 in
the UPS.
1
XM2
XM3
XM4
XM5
XM6
XM7
XM7
XM6
XM3
XM2
1
XM5
XM4
2
