User Manual of DS-9600/8600/7700/7600 Series NVR
151
Before you start:
If you want to enable the UPnP™ function of the device, you must enable the UPnP™ function of the router to
which your device is connected. When the network working mode of the device is set as multi-address, the Default
Route of the device should be in the same network segment as that of the LAN IP address of the router.
Steps:
1. Enter the Network Settings interface.
Menu > Configuration > Network
2. Select the UPnP tab to enter the UPnP™ interface.
Figure 9. 21 UPnP™ Settings Interface
3. Check checkbox to enable UPnP™.
4. Click to open the External Port Settings dialog box. Configure the external port No. for server port, http
port and RTSP port respectively.
Notes:
1) You can use the default port No., or change it according to actual requirements.
2) External Port indicates the port No. for port mapping in the router.
3) The value of the port No. should between 1 and 65535 and the value must be different from each other.
Figure 9. 22 External Port Settings Dialog Box
5. You can click to get the latest status of the port mapping.
