Manual No. 4801-3008 Rev 8-08

Evolution Bird Scale Quick Start Manual

5 of 10

Main Menu
Bird Weigher Vx.x
1. Date/Time

1. Date/Time

Date: 2008/01/01
Time: 15:23:41

2.3

Set the Voltage Selector Switch to the Proper Voltage

Set it to the corresponding power supply (115 or 230 V).



2.4

Power-Up the Controller.

2.5

Set the Time and Date.

• Select the "1. Date/Time" menu from the main menu then press the right-

arrow key. The year begins to flash. Use the adjustment buttons to set the
year.

• Press the right-arrow key. The month flashes on the display. Use the

adjustment buttons to set the month.

• Press the right-arrow key. The day flashes on the display. Use the

adjustment buttons to set the day.

• Press the right-arrow key. The hour flashes on the display. Use the

adjustment buttons to set the hour. The clock is in 24 hour time.

• Proceed in similar fashion to set minutes and seconds.
• Press the left-arrow as many times as required to exit this menu.
Viewing the Day of the Week

• Select "1. Date/Time" from the main menu then press the right-arrow

key.

• Select "2. Day of week" then press the right-arrow key. The current day of the week is displayed. This value is

automatically determined by the controller, it cannot be changed.

2.6

Enter the Installer Password to Access the Installation Menu.

For security reasons, a password is required to access the installation
mode. The password is made up of three blocks of two digits. By
default, the
installer password is set to 03 05 14. The password
cannot be changed.
• Select the "9. Password" menu from the main menu then press

the right-arrow key. The current mode is displayed.

• Press the right-arrow key once again. The first two digits of the

password flash on the display.

• Use the adjustment buttons to set the first two digits of the

password. Press the right-arrow key.

• Proceed the same way to set the second and third two digits. Press

the right-arrow key to validate the password. If the password
entered is incorrect, the message "Wrong Password" is
displayed.

9. Password

Current mode:
User 1

9. Password

Enter password:
00 ** **
