Hired-Hand Evolution Series 3000/3001: Feed Manager - Manual (Page 9)

Part No. 4801-2994 Rev 10-05 FEED MANAGER Page 9 of 22
P2 – Feed Sensors Activated
This general parameter is used to turn additional feed bins ON (press the ‘+’ button) or OFF (press the ‘-‘
button). For example, if you only have two feed bin sensors connected to this control, you can disable bins
#3 and #4 displays by setting this to “1 2 - -“.
P3 – Feed Sensor Type
Program selection not available at this time.
P4 – Feed Sensor Dead Zone (ft, m)
Dead Zone refers to the area that the sensor is hanging into the feed bin. The figure below shows how to
measure the Dead Zone. The measurement should be taken from the top of the cap (excluding the lid ring)
to the bottom of the sensor probe. This measurement is the Dead Zone that should be entered.
P5 – Reset Feed Levels
Select ‘Yes’ to reset the feed bin level. The feed level indicators will reset to the lowest level and
gradually climb to the current feed level.
Dead Zone
