Wiring diagrams, schematics, etc – Hired-Hand Evolution Series 3000/3001: Feed Manager User Manual
Page 15
Part No. 4801-2994 Rev 10-05
FEED MANAGER
Page 15 of 22
8. Wiring Diagrams, Schematics, etc.
The following diagrams describe the Feed Manager circuit board connections and how the Feed manager is
connected to external equipment.
8.1
Feed Manager Circuit Board Layout
HH.Net
1.2 Amp Slo-Blow Fuse – F1
Auxiliary
Alarm
AC Power
Connector
Net Term
Jumper
Voltage
Selector
Switch
Auger #1
Auger #2
Feed Bin # 1
Feed Bin # 2
Feed Bin # 3
Feed Bin # 4
Option Board
Connection
Processor
