Replacement and optional parts – Hired-Hand Evolution Series 3000/3001: Feed Manager User Manual
Page 21
Part No. 4801-2994 Rev 10-05
FEED MANAGER
Page 21 of 22
9. Replacement and Optional Parts
Controls Description Notes
6607-8036 Feed
Manager
6407-6036
Feed Bin Level Sensor
6407-6070 Current
Sensor
6606-2000
Sens-O-Matic III, 120 vac SM-3-I-126S
6606-2100
Sens-O-Matic III, 230 vac SM-3-I-246S
Replacement Parts
Door Assembly
6407-0617
/Door Assy Feed Manager
Terminal Blocks
3006-5076
CONN Terminal Block 2 pos
3006-5077
CONN Terminal Block 3 pos
3006-5078
CONN Terminal Block 4 pos
3006-5082
CONN Terminal Block 3 pos Magnum (Green)
For AC Supply
Fuses
3010-3001
FUSE 1.2 AMP 5mmX20mm slow blow (F1)
Chips
3701-6068
PIC Feed Manager (Processor)
Sensors and Wire
1503-2963
Cable, 20AWG-3C PVC M3273
(Use with Feed Level Sensor)
Manuals
4801-2994
MANUAL Feed Manager
4801-2998
MANUAL Feed Level Sensor
