FEED MANAGER
Page 19 of 22
8.5
Connecting an Alarm to the Feed Manager
Feed Manager
Inset A
For Parallel
Alarm Connection
For Series
Alarm Connection
Internal Circuit Board
Auxiliary Alarm Relay
NOTE: The internal wiring shows the condition of
the relay during normal conditions (no
alarm present). During an alarm
condition, the contact positions will be
reversed.
