System 500™ Power Curtain™ Controller 28
Part No. Description
1018-2059 STND_OFF SCBS-8N
1039-2031 KNOB 1" dia 1/4 shft indctr
1042-2693 FUSE HLDR Shock safe Lit fuse
3010-2139 Fuse 10 AMP 1/4X1-1/4 fst act
3010-2291 Fuse 2 AMP 1/4X1-1/4 fst act
3010-2527 Fuse 2 AMP 5mmX20mm fsc act
3010-0102 Fuse 15 AMP 5mmX20mm fsc act
3540-0127 DIGITAL_IC SRAM 2Kx8
6407-1191 /PCB119 PVR-H w QA
6407-1236 /PCB134 external var/spd w QA
6407-2593 /Temperature sensor assy
Chart A
Part No. Description
6407-1203 /PCB130 S05-CON-8-0 w QA 120V
6407-1211 /PCB130 S05-CON-8-0 w QA 240V
6407-1214 /PCB130 S05-CON-8-V w QA
6407-1216 /PCB130 S05-TUN-8-0 w QA
6407-1218 /PCB130 S05-OSC-8-V w QA
6407-1219 /PCB130 S05-CON-8-V w QA 240V
6407-1220 /PCB130 S05-TUN-8-0 w QA 240V
6407-1221 /PCB130 S05-CON-8-V w QA 240V
Chart B
Part No. Description
3701-0111 EPROM S05-OSC-8-0 V. ENG
3701-0112 EPROM S05-OSC-8-0 V. MET
3701-0113 EPROM S05-OSC-8-V V. ENG
3701-0114 EPROM S05-OSC-8-V V. MET
3701-0115 EPROM S05-CON-8-0 V. ENG
3701-0116 EPROM S05-CON-8-0 V. MET
3701-0117 EPROM S05-CON-8-V V. ENG
3701-0118 EPROM S05-CON-8-V V. MET
Chart C
Part No. Description
6407-0510 DOOR Assembly S05-OSC-8-0 ENG
6407-0511 DOOR Assembly S05-OSC-8-0 MET
6407-0512 DOOR Assembly S05-OSC-8-V ENG
6407-0513 DOOR Assembly S05-OSC-8-V MET
6407-0514 DOOR Assembly S05-CON-8-0 ENG
6407-0515 DOOR Assembly S05-CON-8-0 MET
6407-0516 DOOR Assembly S05-CON-8-V ENG
6407-0517 DOOR Assembly S05-CON-8-V MET
