System 500™ Power Curtain™ Controller

12

If the Target Temp is set at 80 degrees, Offset at 4 degrees and Differential set at 2
degrees, The System will disengage Heat Mode when building temperature reaches 76
degrees.

Target Temp

-

Offset

=

Heat Mode Off

80

-

4

=

76

Cool Mode:

If the Target Temp is set at 80 degrees, Offset set at 5 degrees, and Differential set at 2
degrees, The System will engage the fans when building temperature reaches 87
degrees.

Target Temp

+

Offset

+

Differential

=

Cool Mode On

80

+

5

+

2

=

87

If the Target Temp is set at 80 degrees, Offset set at 5 degrees, and Differential set at 2
degrees, The System will disengage the fans when building temperature reaches 85
degrees.

Target Temp

+

Offset

=

Cool Mode Off

80

+

5

=

85

The stages offset and differential are determined by the program you have

selected with the program bank, and stages switches on the inside of the

controller. A list of all the stage programs is printed at the back of this manual.

8.

Maintenance

There are few items on the System 500™ which require maintenance. This does not mean that
maintenance is not important. Check the calibration of your sensors at least once every two months.

9.

Wiring Diagrams

Recommended Wiring for LOW VOLTAGE hookup.

Component

HHI Wiring Part No. Recommended Wire

Sensor

1502-2427

18/2 Shielded Cable

Hall Effect Devices

1502-2427

18/2 Shielded Cable

PVR-H

1503-1508

18/3 Cable SJT
