Operational Indicator Lights
The externally located operational indicator lights are provided to assist in troubleshooting the heater.
Refer to the following pages for additional troubleshooting information.
13
3.0
Operation • Diagnostics
AG1
Series
Figure 3.1
•
Operational Indicator Lights
VALVE
PS
PRESSURE
SWITCH
V
Light 1
Indicates Valve
Opens
Light 2
Indicates Pressure
Switch Closes
Operational Indicator Lights
