Super Saver Bunsen Jet Brooder with SPI
10
6.1.2. Hanging SPI Galvanized Brooder with 34” Diameter Canopy
The hanging kit for the 34” diameter galvanized steel brooder canopy includes
an 11” chain and two 6” chains which must be attached as shown in Fig. 8 to
ensure that the canopy will hang level. Join the three chains at the center of the
canopy with a single S-hook. Connect the two 6” chains (with S-hooks) to the
holes in the tops of the left and right suspension rods. Connect the 11” chain
(with an S-hook) to the top of the suspension rod directly opposite the controls
enclosure. Be sure to crimp the ends of the S-hooks with pliers before hanging
the unit. This will help minimize the chance of the hooks straightening out. If
your brooder does not hang level, the length of the 11” chain may be adjusted as
required to level the brooder. Use a carpenter’s level to check that the brooder is
level.
Figure 8
34” Diameter Galvanized Canopy
Note: It is important that the brooder canopy
remains level at all times.
Suspension S-hook
Pulleys
