Pos. Designation
14 Retractable lifting eye, max. load 5000 N
15 Capsule intake shaft
16 Intake opening for combustion air
17 Fuel feed line with fuel prefilter
18 Fuel return line
19 Cover plate on exhaust side
20 Central connector for electrical equipment
21 Battery connections
22 Powerbox
23 Electrical maintenance switch for air filter
Engine 4L42C
Encapsulated model "Silent Pack"
Pos. Designation
1 Electronic control unit
2 Oil filling opening and dipstick
3 Type plate
Engine design 2-4L41C, 2-4M41, 2-4M41Z, 4L42C, 4M42
