Technical data
4.1
Engine
Type
2L41C
2M41.
3L41C
3M41.
4L41C /
4L42C
4M41. / 4M42
Type
Air-cooled four stroke diesel engine
Combustion system
Direct injection
Number of cylinders
2
3
4
Bore/stroke
mm
102 / 105
102 / 105
102 / 105
Displacement
cm
3
1716
2574
3432
Engine oil pressure at oil
temperature of 100 ±
20°C
Min. 0.6 bar at 850 rpm
Engine oil consumption
(after running-in period)
Max.
1% of fuel consumption, pertaining to full load
Sense of rotation
When viewing flywheel: left
Tappet clearance at 10 -
30 °C
Inlet/outlet
mm
0,10
Net weight
.M41
.M41Z
4M42
.L41C
4L42C
Approx.
kg
258
263
303
308
315
363
373
388
378
433
438
Max. perm. inclination
during continuous opera-
tion in direction
with / with-
out
oil sump
with
oil sump
without
oil sump
only with
oil sump
Operating side
Exhaust air side
Timing cover side
Flywheel side
30°
1)
30°
1)
30°
1)
30°
1)
30°
1)
30°
1)
25°
1)
22°
1)
25°
1)
30°
1)
25°
1)
25°
1)
25°
1)
30°
1)
15°
1)
18°
1)
Battery capacity
Min/max
12 V – 88/143 Ah / 24 V – 55/110 Ah
1)
Exceeding these limit values causes engine damage.
