11
Installing the Motherboard
Installation Procedure
These modules can be installed with up to 2
GB system memory. Refer to the following
to install the memory module.
1. Align the memory module with the
DIMM slot. There is a notch on
the DIMM slot that you can install
the DIMM module in the correct
direction. Match the cutout on the
DIMM module with the notch on
the DIMM socket.
2. Insert the memory module to the
slot and press it down until it seats
correctly.
3. Make sure the slot latches cling to
the edge of the DIMM module.
