3
Introducing the 3L Small Form Factor
Onboard LAN
The onboard LAN controller provides either of the following features:
• Integrated 10BASE-T/100BASE-TX Transceiver
• Integrated IEEE802.3z cpmpliant
• IEEE802.3u Auto-Negotiation
The motherboard comes with the following expansion options:
• One SCN1 slot (MINI PCI Express slot)
• One SATA_HDD1 and one SATA_ODD1 connectors
Expansion Options
3. To achieve better performance and air flow, we suggest that you use a
system fan on this motherboard.
The motherboard supports UDMA bus mastering with transfer rates of 100/66/33
Mb/s.
Integrated I/O
BIOS Firmware
• One serial port
• One VGA port
• Two PS/2 ports for mouse and keyboard
• Four USB ports
• One LAN port
• One J1 port (DC Jack)
• Audio jacks for microphone, line-in and line-out
The motherboard has a full set of I/O ports and connectors:
The firmware can also be used to set parameters for different processor clock
speeds.
This motherboard uses AMI BIOS that enables users to configure many system
features including the following:
• Power management
• Wake-up alarms
• CPU parameters
• CPU and memory timing
1. Some hardware specifications and software items are subject to change
without prior notice.
2. Due to chipset limitation, we recommend that motherboard be oper-
ated in the ambiance between 0 and 50
° C .
