5
Introducing the 3L Small Form Factor
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
* stands for optional components.
LABEL COMPONENTS
1. SODIMM2* One 200-pin DDR2 SDRAM SODIMM
2. CN3 Power switch
3. SODIMM1 One 200-pin DDR2 SDRAM SODIMM
4. CLR_CMOS Clear CMOS jumper
5. CN2* Reader Card
6. JUSB1~2 Front panel USB ports
7. JMIC1 Front audio line-out
8. JPHONE1 Front audio microphone
9. SATA_HDD1 Serial ATA HDD connector
10. USBPWR_R Rear panel USB PS/2 power select jumper
11. CPU_FAN1 CPU cooling fan connector
12. SATA_ODD1 Serial ATA ODD connector
13. SCN1
MINI PCI Express slot
