General specifications – Proface AGP3300H - 5.7 Handheld HMIs" User Manual
Page 3

3
General Specifications
Electrical Specifications
Environmental Specifications
Po
wer Supp
ly
Input Voltage
DC24V
Rated Voltage
DC19.2 to 28.8V
Allowable
Voltage Drop
2ms (max.)
Power
Consumption
13W (max.)
In-Rush
Current
60A (max.)
*1
*1 The FWHM (Full-width, half maximum) value is approximately 40µs. (When exceeding 30A)
Voltage Endurance
AC1000V 20mA for 1minute (between charging and FG terminals)
Insulation Resistance DC500V 10M
Ω (min.) (between charging and FG terminals)
Phy
s
ic
al
Surrounding Air
Temperature
0 to +50
°C
*1
*1 When using AGP3200-A1-D24 in an environment where the temperature becomes or exceeds 40°C
for an extended period of time, the screen contrast level may decrease from its original level of
brightness.
Storage
Temperature
-20 to +60
°C
Ambient Humidity
10 to 90% RH
(Wet bulb temperature: 39°C max. - no condensation.)
Storage Humidity
10 to 90% RH
(Wet bulb temperature: 39°C max. - no condensation.)
Dust
0.1mg/m
3
and below (non-conductive levels)
Pollution Degree
For use in Pollution Degree 2 environment.
