3. At Password?, type the setup password and then press the OIT’s ENTER key. If there is

no setup password, just press the OIT’s ENTER key. Down/Upload mode? Y displays.

4. At Down/Upload mode?, press the OIT’s Period (.) key to alternate between Y and N,

then press the OIT’s ENTER key to accept and continue.

Option

Description

Result

Allows you to enter

Download/Upload mode

for communication with

STEPware-100.

Displays: Ready for Transfer

to/from STEPware!

Refer to the STEP1 Protocol Operation Manual

Chapter 1: Getting Started for instructions on

creating and downloading a STEPware-100 project.

Displays the OIT’s current

operating parameters.

Displays the first operating parameter (refer to

step 5).

5. The following Level 1 menus appear in order. If you select YES at a Level 1 menu, the

corresponding Level 2 menus appear. If you select NO at a Level 1 menu, the next

Level 1 menu appears. At any menu, press the OIT’s Period (.) key to alternate

between the options.

Level 1 Menus

Level 2 Menus

Options

Disp View Angle:

75d, 90d

Modify communication

parameters?

Baud Rate:

Parity:

Data Length:

Stop Bits:

300, 600, 1200, 2400, 4800, 9600, 19200

NONE, ODD, EVEN, MARK, SPACE

7, 8

1, 2

Modify operating

parameters?

Op Mode:

Handshake:

Line Term:

Append LF:

Local Echo:

Block Echo:

Turn Delay:

Delayed LF:

RS485 3 Wire:

Network Address:

INTERACTIVE, BLOCK, NETWORK

NONE, XON/XOFF, RTS/CTS, BOTH

CR, LF, CR/LF, ETX

ENABLED, DISABLED

NONE, 50 MSEC, 100 MSEC, 250 MSEC

NO, YES

1 to 255

Modify display/keybd

parameters?

Tab Width:

Cursor:

Wrap Around:

Key board:

KeyClick:

Setup Access:

Setup Password

1 SPACE, 4 SPACES, 8 SPACES

UNDERLINE, NONE

ENABLED, DISABLED

NO, YES

5 numbers in any combination

Setup correct?

YES — saves changes and exits

Configuration mode.

NO — returns to Down/Upload mode?

(refer to step 4).
