Append Linefeed Setting

This parameter determines whether a linefeed

control character (0x0A) will be

appended to any carriage return

control character (0x0D) that is sent to the OIT from

the host controller. If enabled, this will cause the cursor of the OIT display to move

down to the next line of the display when a

is received from the host. This feature is

useful when using controllers which can send ASCII strings followed by a

control

character but are unable to append the

control character to any ASCII string sent.

Without sending a

control character, the host is forced to display characters on the

OIT screen on one line of the display only. This feature allows any host that is unable to

send the

control character to use all of the lines of the OIT display.

Factory Default: Disabled
To modify this parameter using STEPware-100:
1. Open the Configuration Editor.
2. In the OIT Operational Settings group box, select the Append Line Feed check box.
To modify this parameter in Configuration mode:
1. At Append LF:, use the OIT’s Period (.) key to enable or disable the Append Line

Feed feature. Refer to the Configuration Mode section in this chapter for more

information.

To modify this parameter from the host controller:
1. This feature cannot be changed from the host controller.

Local Echo Setting

This parameter determines whether local echo is used when the OIT is operating in

Interactive mode. If enabled, each character sent to the host controller from an OIT

keypress is also sent to the OIT’s display.
Factory Default: Enabled
To modify this parameter using STEPware-100:
1. Open the Configuration Editor.

2. In the OIT Operational Settings group box, select the Local Echo Enabled check box.
To modify this parameter in Configuration mode:
1. At Local Echo:, use the OIT’s Period (.) key to enable or disable local echo. Refer to

the Configuration Mode section in this chapter for more information.

To modify this parameter from the host controller:
1. Use the Display Format control command. Refer to Appendix A: Control Commands

for more information.
