PIcon II
Diagnostics
Rev 1.0
January 2014
39
PIcon II Code Update
Contact PIE for upgrade files, which can be loaded via PIE’s STM32 Update Loader. This utility
Before beginning this procedure, close Hyperterm. Proceed with Code Update as follows:
•
Connect the A to B USB cord between the computer and the PIcon II.
•
Power down the PIcon II.
•
Locate the small round hole beneath the power connection on back of the PIcon II.
•
Using a small pointed object, such as a straightened paper clip, press and hold for
approximately five seconds while powering up.
•
Open STM32 Update Loader and use these settings:
Port Name
Com port # for Diagnostics
Baud Rate
256,000
Parity
Even
Echo
Disabled
Timeout(s)
0
Select Next.
•
Screen will read, “Target is readable. Please click ‘Next’ to proceed. Select Next. ” If
this, or a similar message, does not appear, close program and go back to the first step.
•
Verify that Target is STM32_XL_density_1024K. Select Next.
•
Ensure that “Download to device” is selected. Select the file in “Download from file”.
Leave all other options on this page as they are. Select Next.
•
Close STM32 Update Loader when complete.
•
Power cycle the PIcon II.
