PIcon II

Reports

Rev 1.0

January 2014

PRN 11 — Shift 3 Totals By Pump (for 3 shifts previous)

PRN 12 — Print Program Settings

PRN 13 — Print Error Queue

PRN 14 — Program Print Header

Select the report number of the report to be printed and enter it on the PIcon II keypad, then

press . The chosen report will be printed and the display will return to PRN 0.

To exit OPR 2/MGR 3, press the key. MGR 0, the mode entry prompt, will

appear on the display. To return to operator mode, press the key again.

PRN 14 – Print Header – Initiate programming of Print Header by pressing <14> from

the opening print screen, PRN 0. The display will show the beginning information for the

print header. If the header has not already been programmed or has been cleared, the

cursor will prompt for the first character entry. Refer to Table: Print Header Character

Codes at the end of this section for a numeric code which represents the characters

available for your use on the printer header. Determine the character you wish to place

in the first position of the header and look up the numeric code. Enter this numeric code

on the keypad and press . The character will appear on the display, and has

been saved in memory. For each subsequent character, follow the same sequence.

There are two special numeric codes for the header: <10> indicates a new line in the

header; <01> is the code for end of header. Enter the new line code at the point where

the printer should cease printing on the current line and go to the beginning of the next

line. The end of header code is entered after the entire header is entered and will tell the

PIcon II that no more characters are needed in the header.

Special editing features are available for use under Print Header:

without entering a numeric code — Display cursor will increment to next

character in the header.
