PIcon II Operation
Rev 1.0 January 2014 9
The LEDs below each of the pump numbers are the status indicators for that particular
dispenser/fueling position. The green LED on the top indicates Call/In Use. The red LED on the
bottom indicates Collect/Stopped. Table: LED Indicators, below, shows the various states
these LEDs represent for each dispenser/fueling position.
GREEN LED RED LED STATUS
Fast Flash — Call for service
On Solid — Authorized
— Slow Flash Collect "A" Sale
— On Solid Dispenser Stopped
Fast Flash and Fast Flash Drive-Away
Slow Flash and Slow Flash Collect "A" and "B" Sales
Table: LED Indicators for Dispenser/Fueling Positions
