A-16 INSTALLATION
POWER WAVE ® AC/DC 1000 ® SD
A-16
MAXsa™ 19 SYSTEM CHECKLIST (See Figure A.9)
Place the Power Wave ® AC/DC 1000 ® SD in a suitable operating location.
DeviceNet PLC controlled systems: Mount DeviceNet PLC controller and User Interface.
Mount MAXsa™ 19 in itʼs operating location.
Connect K2683-xx Heavy Duty ArcLink Control Cables (5 pin) between Power Wave ® AC/DC 1000 ® SD and
MAXsa™ 19.
Connect K1785-xx Wire Feeder Control Cable (14 pin) between the MAXsa™ 19 and the MAXsa™ 29.
DeviceNet PLC controlled systems: Connect each Arc Master power source to the PLC via the DeviceNet
network.
Install Work Voltage Sense Lead (21) from Power Wave ® AC/DC 1000 ® SD per recomennded guidelines.
Connect / Install welding cables per recommended "Output Cable Guidelines" (Table A.1).
Open the Power Wave ® AC/DC 1000 ® SD front panels and configure DIP switch settings per the decal on the
panel. Factory setting is “Master-Lead”.(See Figure A.4).
Connect input power to Power Wave ® AC/DC 1000 ® SD per recommended guidelines.
Turn on Power Wave ® AC/DC 1000 ® SD and verify all system Status Lights are solid green.
DeviceNet PLC controlled systems: Run Weld Manager. For each Arc Master connect to the power source.
Under Network Settings -> DeviceNet-> Configuration, configure the DeviceNet MAC address and baud rate.
Run Weld Manager. For each Arc Master connect to the power source. Under Feeder Settings -> Wire
Feeder, verify the appropriate Feeder and gear ratio are selected.
Confirm that latest software is updated in all equipment prior to installation (www.powerwavesoftware.com)
Select a Welding process and configure starting and ending options.
