Installation – Lincoln Electric IM10022 POWER WAVE AC_DC 1000 SD User Manual
Page 17
A-8
INSTALLATION
POWER WAVE
®
AC/DC 1000
®
SD
A-8
CRUISER™ SYSTEM CHECKLIST (See Figure A.5)
Place the Power Wave
®
AC/DC 1000
®
SD in a suitable operating location.
Place the Cruiser™ Tractor in itʼs operating location.
Connect K2683-xx Heavy Duty ArcLink Control Cable (5 pin) between Power Wave
®
AC/DC 1000
®
SD and
the Cruiser™ Tractor
Install Work Voltage Sense Lead (21) from the Power Wave
®
AC/DC 1000
®
SD per recommended guidelines.
Connect / Install welding cables per recommended "Output Cable Guidelines" (Table A.1).
Open the Power Wave
®
AC/DC 1000
®
SD front panel and check the DIP switch settings per the decal on the
panel. Factory Setting is “Master-Lead”. (See Figure A.4).
Connect input power to Power Wave
®
AC/DC 1000
®
SD per recommended guidelines.
Confirm that latest software is updated in all equipment prior to installation (www.powerwavesoftware.com)
Turn on Power Wave
®
AC/DC 1000
®
SD, and verify all system Status Lights are solid green.
Select a Welding process and configure starting and ending options.
