A-12 INSTALLATION
POWER WAVE ® AC/DC 1000 ® SD
A-12
TANDEM ARC (2-ARC) SYSTEM CHECKLIST (See Figure A-7)
Place the Power Wave ® AC/DC 1000 ® SD units in a suitable operating location.
Mount MAXsa™ 10 Controllers.
Install MAXsa™ 22 Wire Drives and other accessories in their operating location.
Connect a K1785-xx Wire Feeder Control Cable (14 pin) between the two power sources (top connectors).
Connect K2683-xx Heavy Duty ArcLink Control Cables (5 pin) between Power Wave units and MAXsa™ 10
controllers.
Connect K1785-xx Wire Feeder Control Cable (14 pin) between the MAXsa™ 10 controllers and the
MAXsa™ 22 feeders.
Install Electrode Sense Lead (67) at each feeder and the Work Sense Lead (21) from the Lead Power Wave ®
AC/DC 1000 ® SD Master per guidelines.
Connect / Install welding cables per recommended "Output Cable Guidelines" (Table A.1).
Open the Power Wave ® AC/DC 1000 ® SD front panels and configure DIP switch settings per the decal on the
panel. (See Figure A.4).
Connect input power to Power Wave ® AC/DC 1000 ® SD units per recommended guidelines.
Turn on Power Wave ® AC/DC 1000 ® SD and verify all system Status Lights are solid green.
Confirm that latest software is updated in all equipment prior to installation (www.powerwavesoftware.com)
Run the subarc cell configurator from PC Tools (See Section C of this manual or go to www.powerwavesoft-
ware.com).
Select a Welding process and configure starting and ending options.
