AFL2-17A/AB-H61
P a g e 12
OSD Function LCD on / off, brightness up / down, volume up / down, Hot Key
Construction Material PC + ABS plastic front frame
Mounting Panel/Wall/Rack/Stand/Arm (VESA 100 mm x 100 mm)
Front Panel Color Black
Weight (Net/Gross) 6.9 kg / 9.0 kg
Dimensions (W x H x D) (mm) 418 x 378 x 65
Operation Temperature -20ºC ~ 40ºC (Ambient with air flow)
Storage Temperature -20ºC ~ 60ºC
Humidity 10% to 95% (non-condensing)
IP level IP 64 compliant front panel
Power Supply 120W power adapter
Input: 100V AC ~ 240V AC @ 50 / 60 Hz
Output: 19V DC
Power Requirement 9V ~ 36V DC
I/O Ports and Switches 2 x RS-232 (DB-9 connector)
1 x RS-422/485 (DB-9 connector)
2 x GbE LAN (one on bottom side, one on left side)
2 x USB 3.0 connector
3 x USB 2.0 connectors (two on bottom side, one on left side)
1 x Mini USB 2.0 connector (on front panel)
1 x Micro SD card slot (on front panel)
1 x Line-out (on Left side)
1 x Mic (on Left side)
1 x VGA port (DB15 connector)
1 x HDMI port
1 x Power switch
1 x AT/ATX switch
1 x Reset button
1 x Clear CMOS button
1 x 9 V ~ 36V DC input jack
1 x k-type connector
Table 1-4: System Specifications
