AFL2-17A/AB-H61
P a g e 3
1.1.1 Mo d e l Va ria tio n s
The model variations of the AFL2-17A/AB-H61 Series are listed below.
Model No. Touch Screen LED Light Bar
Intel® Core™ i5 Series
AFL2-17A-H61-i5/R-R11 Resistive Touch Yes
AFL2-17AB-H61-i5/R-R11 Resistive Touch No
AFL2-17A-H61-i5/PC-R11 Projected capacitive Yes
AFL2-17AB-H61-i5/PC-R11 Projected capacitive No
Intel® Core™ i3 Series
AFL2-17A-H61-i3/R-R11 Resistive Touch Yes
AFL2-17AB-H61-i3/R-R11 Resistive Touch No
AFL2-17A-H61-i3/PC-R11 Projected capacitive Yes
AFL2-17AB-H61-i3/PC-R11 Projected capacitive No
Intel® Pentium® G6xxT Series
AFL2-17A-H61-P/R-R11 Resistive Touch Yes
AFL2-17AB-H61-P/R-R11 Resistive Touch No
AFL2-17A-H61-P/PC-R11 Projected capacitive Yes
AFL2-17AB-H61-P/PC-R11 Projected capacitive No
Table 1-1: AFL2-17A/AB-H61 Model Variations
1.1.2 Fe a tu re s
The AFL2-17A/AB-H61 features are listed below:
 Programmable colorful LED light bar (for AFL2-17AB-H61 series only)
 2nd Generation Intel® Core™ i7/ i5/ i3, Pentium® and Celeron® processor
 Two 204-pin DDR3 SO-DIMM slots (system max. 16GB)
 Pre-installed 4GB DDR3 1333MHz SO-DIMMs (2GB x 2)
 Projected capacitive touchscreen and 5-wire resistive type touch screen
supported
 Wi-Fi 802.11b/g/n 2T2R high speed wireless
 EM or Mifare RFID reader (on selected models)
 Built-in 2M pixel webcam with AF, AE and AWB capabilities
 Built-in two 2W speakers and microphone
