AFL2-17A/AB-H61
P a g e 141
8.3.9 H/W Mo n ito r
The H/W Monitor menu (BIOS Menu 13) shows the hardware health status.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
CPU Temperature :+62 C
Environment Temperature 1 :+29 C
Environment Temperature 2 :+30 C
SYS Temperature :+61 C
CPU Fan Speed
:3166 RPM
Fanless Temp. Overwrite Control [Enabled]
Temperature of Fanless
[32 C]
Fanless Temperature Reading :+24 C
The Temperature of
Fanless can be set after
this item has been
enabled.
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 13: Hardware Health Configuration
 PC He alth Statu s
The following system parameters and values are shown. The system parameters that are
monitored are:
 System Temperatures:
o CPU Temperature
o Environment Temperature 1 (CN13)
o Environment Temperature 2 (CN14)
o System Temperature
 Fan Speeds:
o CPU Fan Speed
 Fan les s Tem p . Overwrite Co n tro l [En ab led ]
Use the Fanless Temp. Overwrite Control option to enable or disable Fanless Temp.
Overwrite control function. The Temperature of Fanless can be set after this item has
been enabled.
