AFL2-W21A/AB-H61

P a g e 7

1.2.3 Bo tto m P a n e l

The bottom panel of the AFL2-W21A/AB-H61 has the following features (Figure 1-5):

 1 x AT/ATX Switch

 1 x Clear CMOS switch

 1 x 9V ~ 36V DC power jack

 6 x Function keys

 1 x HDMI port

 1 x K-type connector

 1 x Power button

 1 x Reset button

 1 x RJ-45 LAN connector

 2 x RS-232 connectors (COM1,COM2)

 1 x RS-422/485 connector (COM3)

 1 x Temperature sensor

 2 x USB 2.0 connectors

 2 x USB 3.0 connectors

 1 x VGA port

Figure 1-5: AFL2-W21A/AB-H61 Bottom Panel
