AFL2-W21A/AB-H61
P a g e 132

IO=2E8h; IRQ=3,
4, 7,10
Serial Port I/O port address is 2E8h and the
interrupt address is IRQ3, 4, 7, 10
 Device Mo d e [RS422]
Use the Device Mode option to select the serial port mode.

RS422 D EFAULT Enables serial port RS-422 support.

RS485 Enables serial port RS-485 support.
7.3.9 H/W Mo n ito r
The H/W Monitor menu (BIOS Menu 13) shows the hardware health status.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
CPU Temperature :+62 C
Environment temperature 1 :+29 C
Environment temperature 2 :+30 C
SYSTEM temperature :+61 C
CPU FAN Speed
:3166 RPM
CPU Smart Fan control [Auto Mode]
Temperature of Start(°C) 75
Temperature of Off(°C) 60
Start PWM 50
Slope(PWM) [4(PWM)]
Fanless Temp. Overwrite Control [Enabled]
Temperature of Fanless
[32 C]
Fanless Temperature Reading :+24 C
The Temperature of
Fanless can be set after
this item has been
enabled.
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 13: Hardware Health Configuration
 PC He alth Statu s
The following system parameters and values are shown. The system parameters that are
monitored are:
 System Temperatures:
o CPU Temperature
