AFL2-W21A/AB-H61
P a g e 134
 Maximum Value: 150°C
 Tem p eratu re o f Off [60]
WARNING:
Setting this value too high may cause the fan to speed up only when
the CPU is at a very high temperature and therefore cause the system
to be damaged.
The Temperature of Off option can only be set if the CPU Smart Fan control option is
set to Auto Mode. When the CPU Temperature is higher than Temperature of Off, the
fan will be speed up. To set a value, select the Temperature of Off option and enter a
decimal number between 0 and 150. The temperature range is specified below.
 Minimum Value: 0°C
 Maximum Value: 150°C
 Start PWM [50]
The Start PWM option can only be set if the CPU Smart Fan control option is set to Auto
Mode. Use the Start PWM option to set the PWM start value. To set a value, select the
Start PWM option and enter a decimal number between 0 and 100. The temperature
range is specified below.
 Minimum Value: 0
 Maximum Value: 100
 Slo p e (PWM) [4]
The Slope (PWM) option can only be set if the CPU Smart Fan control option is set to
Auto Mode. Use the Slope (PWM) option to select the linear rate at which the PWM mode
increases with respect to an increase in temperature. A list of available options is shown
below:
 0 (PWM)
