AFL2-W21A/AB-H61
P a g e 91
Figure 5-22: LOGO LED Connector Location
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 2 +V3.3S
Table 5-19: LOGO LED Connector Pinouts
5.2.20 Min i US B Co n n e c to r
CN La b e l: MINUS B1, MINUS B2
CN Typ e : 4-pin wafer
CN Lo c a tio n : See Figure 5-23, Figure 5-24
CN P in o u ts : See Table 5-20
The Mini USB connector connects to USB devices.
