6.3.1 CPU Configuration
Use the CPU Configuration menu (
597H597H597H597H596H596H
BIOS Menu 3 ) to view detailed CPU specifications
and configure the CPU.
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
Configure Advanced CPU Settings
Module Version – 3F.13
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
Manufacturer :Intel®
Genuine Intel® CPU 575 @ 2.00GHz
Frequency :2.00GHz
FSB Speed :668MHz
Cache L1 : 32 KB
Cache L2 : 1024 KB
Ratio Actual Value:12
ÅÆ Select
Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 3: CPU Configuration
The CPU Configuration menu (
598H598H598H598H597H597H
BIOS Menu 3 ) lists the following CPU details:
ƒ Manufacturer: Lists the name of the CPU manufacturer
ƒ Brand String: Lists the brand name of the CPU being used
ƒ Frequency: Lists the CPU processing speed
ƒ FSB Speed: Lists the FSB speed
ƒ Cache L1: Lists the CPU L1 cache size
ƒ Cache L2: Lists the CPU L2 cache size
6.3.2 IDE Configuration
Use the IDE Configuration menu (
599H599H599H599H598H598H
BIOS Menu 4 ) to change and/or set the configuration
of the IDE devices installed in the system.
