UPC-12A/GM45 Panel PC
Page 54
4.11.4 USB Device Connection
There are four external USB 2.0 connectors. All connectors are perpendicular to the
UPC-12A/GM45 series. To connect a USB 2.0 or USB 1.1 device, please follow the
instructions below.
Step 1:
Located the USB connectors
. The locations of the USB connectors are shown
in Chapter 2.
Step 2:
Align the connectors.
Align the USB device connector with one of the
connectors on the I/O interface panel. See
573H573H573H573H573H573H
Figure 4-24
.
Figure 4-24: USB Device Connection
Step 3:
Insert the device connector.
Once aligned, gently insert the USB device
connector into the onboard connector.
Step 0:
4.11.5 VGA Monitor Connection
The UPC-12A/GM45 has a single female DB-15 connector on the bottom panel. The
DB-15 connector is connected to a CRT or VGA monitor. To connect a monitor to the
UPC-12A/GM45, please follow the instructions below.
