IMBA-9454G Motherboard
Page 35
Connector Type Label
Serial port connector (RS-422/485) 4-pin header CN1
SPDIF connector 5-pin header CN5
TPM connector 20-pin header TPM1
USB connector 8-pin header USB3
USB connector 8-pin header USB4
Table 4-1: Peripheral Interface Connectors
4.1.3 External Peripheral Interface Panel Connectors
Table 4-2 lists the external peripheral interface panel connectors on the IMBA-9454G.
Detailed descriptions of these connectors can be found in.
Connector Type Label
Keyboard/Mouse PS/2 KBMS1
Parallel port connector DB-25 (female) 3IN1_DSUB1A
Ethernet/USB connector RJ-45/USB port combo connector LAN/USB1B
Ethernet/USB connector RJ-45/USB port combo connector LAN/USB2B
Audio connector 3 x Audio jacks CN6
VGA connector DB-15 (female) 3IN1_DSUB1C
Serial connector DB-9 (male) 3IN1_DSUB1B
Table 4-2: External Peripheral Interface Panel Connectors
4.2 Internal Peripheral Connectors
Internal peripheral connectors are found on the motherboard and are only accessible
when the motherboard is outside of the chassis. This section has complete descriptions of
all the internal, peripheral connectors on the IMBA-9454G.
4.2.1 ATX Power Supply Connector (4-pins)
CN Label: CPU12V1
