Bios menu 7: super io configuration – IEI Integration IMBA-9454 v4.02 User Manual
Page 131

IMBA-9454G Motherboard
Page 113
BIOS SETUP UTILITY
Main
Advanced
PCIPnP
Boot
Security
Chipset
Exit
Configure ITE8712 Super I/O Chipset
Serial Port1 Address
[3F8/IRQ4]
Serial Port1 Mode
[Normal]
Serial Port2 Address
[2F8/IRQ3]
Serial Port2 Mode
[Normal]
Parallel Port Address
[378]
Parallel Port Mode
[Normal]
Parallel Port IRQ
[IRQ7]
Serial Port3 Address
[3E8]
Serial Port4 Address
[2E8]
Serial Port5 Address
[2F0]
Serial Port6 Address
[2E0]
Allows BIOS to Select
Serial Port1 Base
Addresses.
Select
Screen
Select
Item
+ - Change Option
F1 General
Help
F10
Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 7: Super IO Configuration
Serial Port1 Address [3F8/IRQ4]
Use the Serial Port1 Address option to select the Serial Port 1 base address.
Disabled
No base address is assigned to Serial Port 1
3F8/IRQ4 D
EFAULT
Serial Port 1 I/O port address is 3F8 and the interrupt
address is IRQ4
3E8/IRQ4
Serial Port 1 I/O port address is 3E8 and the interrupt
address is IRQ4
2E8/IRQ3
Serial Port 1 I/O port address is 2E8 and the interrupt
address is IRQ3
Serial Port1 Mode [Normal]
Use the Serial Port1 Mode option to select the Serial Port1 operational mode.
Normal
D
EFAULT
Serial Port 1 mode is normal
IrDA
Serial Port 1 mode is IrDA
ASK IR
Serial Port 1 mode is ASK IR
