IMBA-9454G Motherboard
Page 125
COM3 D
EFAULT
System is remotely accessed through COM3
COM4 D
EFAULT
System is remotely accessed through COM4
COM5 D
EFAULT
System is remotely accessed through COM5
COM6 D
EFAULT
System is remotely accessed through COM6
NOTE: Make sure the selected COM port is enabled through the Super I/O configuration
menu.
Base Address, IRQ [3F8h, 4]
The Base Address, IRQ option cannot be configured and only shows the interrupt
address of the serial port listed above.
Serial Port Mode [115200 8,n,1]
Use the Serial Port Mode option to select baud rate through which the console redirection
is made. The following configuration options are available.
115200
8,n,1 D
EFAULT
57600
8,n,1
38400
8,n,1
19200
8,n,1
09600
8,n,1
NOTE:
Identical baud rate settings must be set on the host (a management
computer running terminal software) and the slave.
Redirection After BIOS POST [Always]
Use the Redirection After BIOS POST option to specify when console redirection should
occur.
Disabled
The console is not redirected after POST.
