6.3.5 Hardware Health Configuration
The Hardware Health Configuration menu (BIOS
8) shows the operating
temperature, fan speeds and system voltages.
BIOS SETUP UTILITY
Main
Advanced
PCIPnP
Boot
Security
Chipset
Exit
Hardware Health Configuration
CPU FAN Mode Setting
[Full On mode]
System FAN1 Mode Setting
[Full On mode]
System FAN2 Mode Setting
[Full On mode]
CPU Temperature
:34ºC/93ºF
System Temperature #1
:29ºC/84ºF
System Temperature #2
:25ºC/77ºF
CPU Fan
:3260 RPM
System Fan1 Speed
:N/A
System Fan2 Speed
:N/A
CPU Core
:1.200 V
DRAM Vcc
:1.840 V
+3.30V :3.168
V
+5.00V :4.945
V
+12.0V :11.840
V
FSB Vcc +1.20V
:1.168 V
+1.50V :1.488
V
3VDU
:2.944
V
VBAT
:3.344
V
CPU configuration mode
setting
If Enable Automatic
mode, CPU Fan will refer
to CPU Temperature.
Select
Screen
Select
Item
+ - Change Option
F1 General
Help
F10
Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 8: Hardware Health Configuration
CPU FAN Mode Setting [Full On mode]
Use the CPU FAN Mode Setting to set the CPU fan mode.
Full On
mode
D
EFAULT
Fan is on all the time.
Automatic
The fan adjusts its speed using these settings:
Temp. Limit of OFF
Temp. Limit of Start
Fan Start PWM
