KINO-AQ870

P a g e 21

Figure 3-5: Clear CMOS Button Location

3.2.5 CP U P o we r Co n n e c to r

CN La b e l:

CP U12V1

CN Typ e :

4-pin Molex

CN Lo c a tio n :

See Figure 3-6

CN P in o u ts :

See Table 3-7

The CPU power connector provides power to the CPU.

Figure 3-6: CPU Power Connector Location
