USB connectors
8-pin header,
20-pin box header
USB1, USB2,
CN4
Table 3-1: Peripheral Interface Connectors
3.1.3 Exte rn a l In te rfa c e P a n e l Co n n e c to rs
The table below lists the connectors on the external I/O panel.
Connector Type Label
Audio connector Audio jack AUDIO_CV1
Ethernet and USB connector RJ-45, USB LAN1_USB1,
LAN2_USB2
Keyboard/Mouse Dual PS/2 KB_MS1
RS-232 serial port connector DB-9 male COM1_2
VGA and DVI connector 15-pin female,
24-pin female
VIDEO1
Table 3-2: Rear Panel Connectors
3.2 In te rn a l P e rip h e ra l Co n n e c to rs
The section describes all of the connectors on the KINO-AQ870.
3.2.1 ATX P o we r Co n n e c to r
CN La b e l: ATX1
CN Typ e : 24-pin ATX
CN Lo c a tio n : See Figure 3-2
CN P in o u ts : See Table 3-3
The ATX power connector connects to an ATX power supply.
