2 Warner Electric Europe • +33 (0)2 41 21 24 24 P-2060-WE • 2/13
We, WARNER ELECTRIC EUROPE, 7, rue Champfleur, B.P. 20095, F-49182 St Barthélemy d’Anjou Cedex
declare that the brakes are made in our factory from St Barthélemy d’Anjou,
and hereafter designated : ERD
are exclusively designed for incorporation into a machine and to be assembled with other equipment with a view to constituting a machine to
which direction 98/37/EC and Electromagnetic Compatibility directive 89/336 as amended apply.
The basic requirements of Low Voltage directive 73/23 (modified) are compiled with through full conformity with the following standards:
NFC 79300 and VDE 05808/8.65
Drawn up in St Barthélemy d’Anjou, July 2002
E. PRAT, General Managing Director
CONTENTS
1 Technical specifications 2
2 Precautions and restrictions on use 2
2.1 Restrictions on use 2
2.2 Precautions 2
and safety measures
3 Installation 3
3.1 Transport - storage 3
3.2 Handling 3
3.3 Installing 3
4 Maintenance 3
4.1 Adjusting the airgap 3
4.2 Maintenance 3
4.3 Spare parts 3
5 Electrical connection 4
5.1 Important recommendations 4
5.2 Power supply 4
6 Options 4
6.1 Torque adjustment 4
6.2 Detection kit 4
6.3 Hand release kit 5
6.4 Accessories 6
7 Appendices 6
7. 1 ERD VAR00 and VAR02 6
7.2 Options 6
1 Technical specifications (VAR00 and VAR02)
Table 1
2 Precautions and restrictions on use
2.1 Restrictions on use
This equipment is designed for dry running.
Any oily material alters performance.
Exceeding the maximum rotation speeds
stated in the catalogue invalidates the warranty.
The equipment can be fitted either horizontally
or vertically.
This equipment is designed for an ambient
tem perature of 40°C maximum (155°C
insulation class).
2.2 Precautions and safety measures
During maintenance, ensure that the
mechanism to be braked by the equipment is at
rest and that there is no risk of accidental start-
up. All intervention have to be made by qualified
personnel, owning this manual
Any modification made to the brake without
the express authorization of a representative of
Warner Electric, in the same way than any use
out of the contrac tual specifications accepted by
“Warner Electric”, will result in the warranty being
invalidated and Warner Electric will no longer be
liable in any way with regard to conformity.
ERD Size 005 010 020 035
Nominal torque (standard version) Nm
Nominal airgap +0,1/-0,05 mm
Max. airgap mm
Maximum speed min -1
Tightening torque of screws Nm
5
0,2
0,5
3600
2,4
10
0,2
0,65
3600
4,4
20
0,2
0,55
3600
7,8
35
0,3
0,8
3600
7,8
Symbol designating
an action that might
damage the brake Symbol designating an
action that might be
dan gerous to human safety Symbol designating an
elec trical action that might be
dangerous to human safety
